Description
Specifications
Performance
- Intermittent Flowrate: Adult: 8 LPM , Pediatric: 8 LPM, Neonatal: 8 LPM
- Continuous Flowrate: Adult: 65 LPM, Pediatric: 40 LPM, Neonatal: 40 LPM
- 16 seconds on/ 8 seconds off
- Timing can be adjusted on the back of the unit with access to ON and OFF needle valves, starts in the OFF position
Gauge Accuracy
- Analog: ± 3% Full-scale
- Digital: ± 1% Full-scale
Physical
- Dimensions:
5.94” H x 2.93” W x 4.04” D
(15.09 x 7.44 x 10.26 cm) - Weight:
Continuous: 0.65 lbs (0.29 kg)
Intermittent: 0.8 lbs (0.36 kg)
Battery
- Lithium: 2, 2/3 AA batteries, 3.6 V,
1.6 Ah, lithium
Vacuum Range
- Continuous High/Surgical:
0 – 750 mmHg (94 KPA) - Continuous and Continuous/Intermittent:
0 – 300 mmHg (40 KPA) - Pediatric and Pediatric/Intermittent:
0 – 160 mmHg (20 KPA) - NeoNatal and NeoNatal/Intermittent:
0 – 100 mmHg (13 KPA)
